Super Portable X-ray machine
Model: SHO-PXM01
Fill in the form to get more product information
Product Introduction
Technical specification| Super Portable X-ray machine SHO-PXM01 |
|
| Output （W） | 560 |
| KV range（KV） | 40-70 |
| mA range （mA） |
2-8mA |
| mAs range | 10-2000 |
| Focal spot | 0.4mm |
| Anode angle | 12° |
| Anode heat storage | 4500J（6300HU） |
| Input voltage (VAC) |
Charger 100-240V |
| Dimension | 263X210X210mm |
| Net weight（Kg） | 3.5KG |
Features
Super mini portable X-ray machine with battery
560W, 40-70kv, 2-8mA
Net weight is 3.5kg
Laser Collimator
Has both Human and vet photography modes
Horizontal screen 10.4 inch touch screen
Domestic X-ray tube, High voltage generator
17”*17”wired flat panel detector
Dell brand 15.6inch Laptop computer
Aluminum case
